Getting Started

MicroVAX 3100 Models 88/98 User Information

2-27

Connecting the Power Cord

_________________________Caution ___________________________

Your system uses a momentary switch for On/Off control. Always assume that

your system will come on when the AC power cord is installed.

____________________________________________________________

To connect the power cord, refer to Figure 2-20 and follow these steps:

1. Connect the power cord to the rear of the system.

2. Connect the other end of the power cord to an isolated, grounded circuit.

MLO-013702

Figure 2-20 Connecting the Power Cord
